Product Details

1200℃ open type three-heating zone rotaty tube furnace uses high-purity quartz to make variable-diameter quartz tube, which is specially designed for powder processing. The rotating device adopts friction transmission, and the inclination angle (0-15°) can be adjusted arbitrarily. At the same time, the tube furnace has three heating zones with independent temperature control. Each heating zone can edit 30 sections of temperature rise and fall program, and the equipment also has overheating and break protection functions. The flanges on both sides of the furnace tube are equipped with a digital vacuum gauge and a mechanical pressure gauge, which can be used to control the atmosphere in the furnace tube. If the experiment requires the use of flammable gas, the tube furnace can be equipped with a manual ignition device to complete the exhaust gas treatment to ensure the safety and environmental protection of the experiment.

1200℃ three-heating zone rotary tube furnace application range:
Tube furnaces are mainly used in metallurgy, glass, heat treatment, lithium battery positive and negative materials, new energy, abrasives and other industries, and can also be used for heat treatment in atmospheric environment. It can also be used to form a CVD system for related coating test production.

1200℃ three-heating zone rotary tube furnace technical parameters:

Model	HS-O1200-60III-C-RO
Max power	4.5kw
Furnace tube material	High purity quartz
Furnace tube diameter	60mm at both ends, 100mm in the middle
Furnace tube length	1400mm
Furnace chamber length	600mm
Heating zone length	200mm+200mm+200mm
Operating temperature	0～1100℃
Temperature control accuracy	±1℃
Temperature control mode	30 or 50 segment program temperature control
Display mode	highlight digital tube display
Sealing method	304 stainless steel vacuum flange
Flange interface	1/4" ferrule connector (Ø8 pagoda-shape connector)
Vacuum	4.4E-3Pa
Power supply	AC:220V 50/60Hz
Angle of inclination	0~15°
Rotate speed	0~20 rpm
