Multi-Chamber Glove Box with Gas Purification System (H2O&O2< 1ppm)

Basic InfoModel NO.: HS-Q-EVGB-11Structure: DesktopCertification: CE, TUVType: Heating TypeOperating Gas: Inert GasFilter System: Organic SolventTrademark: CYSpecification: Multi-chamber glove boxHS Code: 85141090Customized: CustomizedMaterial: Stainless SteelApplication: Sch

Products Inquiry

Name * :

Tel * :

Email :

CompanyName :

Message :

Product Details

Product Description
Triple Chambers Glove Box (140" x 32" x 36") with Gas Purification System (H2O&O2< 1ppm) and Mid Openable Front Window - EQ-VGB-11
Introduction
VGB-11 is a triple stainless steel glove box with one middle openable front window designed for researchers in material science, chemistry, semiconductor, and related topics. The purification cylinder is made of BASF antioxidant materials from Germany and UOP water adsorbent materials from the US in order to achieve a low water and oxygen concentration of lower than 1ppm, such that experiments can be conducted in an ultra clean and highly purified gas environment. It is integrated with vapor pressure control system, purity control system, automatic gas purity regeneration control system, auto alarm, and system data log recording. Three slidable shelves are built in the glovebox to make operation at easy. VGB-11 is widely used in preparing nanomaterials, Li-ion battery materials, catalysts, and metallorganics.

Specification

Working Voltage	220V AC, 50/60Hz, Single Phase
Max. Power Consumption	4KW
Glove Box Chamber	Case Material: Stainless Steel 304 Dimensions: 3600mm(L) x800mm(W) x930mm(H) 12mm thick double layer laminated safety glass with corrosion protection film for operating in a safe and easy manner
Chamber Condition	Water concentration:<1 ppm=""> Oxygen concentration:<1 ppm="">
Leak rate	<0.05 vol="">
Air-lock Chamber	Antechamber Dimensions:385mm(Dia.) x588mm(L) Small Chamber Dimensions (for tools):150mm(Dia.) x300mm(L) Max. vacuum level: 100 Pa
Working Gas	Operating gas: Inert gas such as N2, Ar, He Regenerating gas: Mixture of H2 (5%) and Operating gas For purification system with only water adsorbing function, Regenerating gas will be the same as Operating gas
Gas Purification System	Automated Regeneration Process Automated water and oxygen removal Purification Cylinder: made of BASF antioxidant materials and UOP water adsorbent materials Moisture removal capacity: 1.5KG Oxygen removal capacity: 180L
Filter System	Organic Solvent Filter System filled with replaceable activated carbon Built in HEPA filter can eliminate particle size > 0.3um
Control system	Siemens PLC control system with 6" touchscreen display Water concentration: 0 - 1000 ppm with an accuracy of 0.1 ppm Oxygen concentration:< 0 - 1000 ppm with an accuracy of 0.1 ppm Pressure: -2500 to 2500 Pa with an accuracy of 1 Pa
Pump	240L/m Heavy Duty Double Stage Rotary Vane pump or faster gas exhaust Vacuum rate: 7.8 cfm Lowest pressure: 0.4pa
Blower	Flow Rate:90m3/h
Purification Pipeline	304 Stainless Steel, KF40 Port
Gloves	A pair of NORTH Butyl glove is included to provide better protection against toxic materials
Lighting	Built-in fluorescent lamp
Slidable Shelf	Two slidable shelves are built in top of inside glove chamber with dimensions of 300mm x 250mm 300mm away from roof
Product Dimensions	4200mm(L) x830mm(W) x1830mm(H) (165" x 33" x 72")
Shipping Dimensions & Weight	TBD
Feedthrough and Optional	Universal terminal panel is a convenient part with varies feedthrough built-in for VGB-11 series glove boxes to transfer gas/vacuum pipelines, circuit cables, etc. Dimensions:Dia.420x280mm Adapter: 10dia.6 ports, 4dia.8 ports, 4 dia.12 ports
Warranty	One Year limited warranty with lifetime support
