Product Details

Portable infrared carbon dioxide analyzer has a friendly communication menu to make the operation visual and simple. There is no need to do special test and protection to the sensor within test range, making the operation and maintaining easier.It is of good selectivity to the tested gas.
Portable infrared carbon dioxide analyzer main features:
1.Friendly communication menu makes the operation visual and simple;
2.Long calibration interval cycle, high accuracy and reliable stability;
3.The compensation system for temperature can eliminate the change from environment temperature;
4.The function of storing data automatically allows the users to look through the historic data freely;
5.The built-in lithium battery with large capacity is convenient for field operation and easy to maintain;
6.The built-in extraction pump(optional).

Portable infrared carbon dioxide analyzer technical parameters:

Test principle	infrared principle
Display mode	128×64 matrix dot LCD
Test range	0 ~ 30/50/99.9% CO₂
Accuracy	≤± 1.2%FS
Repeatability	≤± 1%
Response time	T₉₀≤15S
Sample gas temperature	-10℃~ 50℃
Sample gas flow	300 ~ 600ml/min
Sampling mode	sample gas pass-in or extraction
Sample gas pressure(without pump)	0.05Mpa≤entrance displayed pressure≤ 0.35Mpa，steady pressure environment
Sample gas pressure(with pump)	micro-positive pressure, micro-negative pressure or ordinary pressure
Appearance Size	155mm×260mm×340mm(H×W×D)
Serving life	＞24 months (under normal use)
Gas circuit port	NPT 1/8 internal thread
Battery specification	lithium battery，11000mAH ,12.6V/2Ah
Charging source	AC170 ~ 264V 50/60Hz
Install mode	portable mode
