Electric Vertical Rolling Press with Variable Speed

Product introductionHS-DG100L Electric Vertical Rolling Press is mainly suitable for electric rolling of battery materials in the laboratory, a small amount of precious metals such as gold and silver, and non-ferrous materials such as copper and aluminum. The rolling thickness

Products Inquiry

Name * :

Tel * :

Email :

CompanyName :

Message :

Product Details

Product introduction	HS-DG100L Electric Vertical Rolling Press is mainly suitable for electric rolling of battery materials in the laboratory, a small amount of precious metals such as gold and silver, and non-ferrous materials such as copper and aluminum. The rolling thickness can be adjusted and the operation is simple. It is especially suitable for thinning and increasing the density of lithium battery plates of clean energy materials.
Main features	Adjustable tablet thickness and speed, easy to use The motor can be turned forward and reverse, easy to return when problems are found during operation Use gear rotation to achieve roller pressing With plexiglass shield
Technical parameters	Rolling thickness: 0 ~ 2mm adjustable Tablet width: 0 ~ 100mm Roller diameter: 2 ~ Φ96mm Roller surface hardness: above HRC60 Roller finish: above 0.8 Roll placement: vertical placement Voltage and frequency: AC220V / 50HZ Power: 120W Feeding speed: 0 ~ 50mm / s adjustable
Specifications	Overall dimensions: L385 * W245 * H355 Equipment weight: 55KG
Standard accessories	One internal hexagonal wrench M4, two dial gauges, one feeler
