Desk-Top Micro-Computer Control Capacitive Discharge Spot Welder (Electric Pedal Type)

Basic InfoModel NO.: HS-MSK-320BCooling Way: Air CoolingElectrode Stroke: ArcTransmission: PneumaticWelding Spot Number: MultipleWelding Time: 1- 99 MsMax. Depth: 8.5cmWarranty: One YearTrademark: HSSpecification: 0.03 - 0.5mm tabHS Code: 85141090Control: AutomaticStyle: Po

Products Inquiry

Name * :

Tel * :

Email :

CompanyName :

Message :

Product Details

Basic Info
Model NO.: HS-MSK-320B
Cooling Way: Air Cooling
Electrode Stroke: Arc
Transmission: Pneumatic
Welding Spot Number: Multiple
Welding Time: 1- 99 Ms
Max. Depth: 8.5cm
Warranty: One Year
Trademark: HS
Specification: 0.03 - 0.5mm tab
HS Code: 85141090
Control: Automatic
Style: Portable
Electric Current: Capacitor Energy Storage
Conductive Way: One-Sided
Type: Special
Welding Current: 1-20A
Controller: Digital LCD
Certificate: Ce/TUV
Transport Package: Wooden Box
Origin: Zhengzhou, China

Product Description
Desk-Top Micro-computer Control Capacitive Discharge Spot Welder (Electric Pedal Type), 208 - 240VAC) - MSK-320B
Introduction of micro spot welder
MSK-320B is a Micro-computer Control Capacitive Discharge Spot Welder. It is designed for the production of the world's high-class battery manufacturer (NiMH. NiCd, Li-Ion/LiMnNi. LifePO4) with more reliable and consistent welding than AC pulse. It is an ideal tool when the welding application requires a rapid rise time and high energy discharge.

Technical parameters of micro spot welder

Working Voltage	208-240V AC, 50/60Hz
Output Power	2 KW (10KW Max. at plus moment )
Welding Current	0-99% Adjustable
Welding probes	Allow independent adjustment for pressure Ensure consistent welding pressure Fully eliminates the phenomenon of low voltage or condensation occurred to lithium batteries after welding Homogeneous welding spot, small spark, and no black spots Quick energy release for welding highly conductive metals such as copper Small heat affected weld zones
Welding Switch	Built in optoelectronic welding switch, which can eliminate the need of changing switches for similar welding machines
Controller	Digital LCD control panel for setting all parameters Welding time: 1- 99 ms Welding current: 1- 20A
Tab Thickness Applicable	0.03 - 0.5mm tab (10 pcs 0.2mm Tab will be provided in the package for customer's practice)
Working Space	Max. Opening between the welding tip and bottom stage is 9cm (19cm by removing the bottom stage) Max. Depth is 8.5cm (measured from the center of the bottom stage till the back end of the machine)
Warranty	One year limited warranty with lifetime support
Product Dimensions	800mm(L) x 580mm(W) x 1200mm(H)
