1200℃ low vacuum rotary CVD system with 3-channel float flowmeter HS-O1200-60IIIC-R

Products Inquiry

Name * :

Tel * :

Email :

CompanyName :

Message :

Product Details

The three temperature zones of the tube furnace are independently temperature controlled by the precision temperature control instrument. By adjusting the temperature of each temperature zone, the tube furnace can form three temperature gradients in the heating zone or form a long constant temperature zone. Each zone can be edited with 30 sections of temperature rise and fall, with overheating and open circuit protection. The flanges on both sides of the furnace tube are equipped with a digital vacuum gauge and a mechanical pressure gauge, which can be used to control the atmosphere environment in the pipeline.
If you need to maintain a single grain structure (such as when drying or calcining materials), a rotary tube furnace is ideal for you. The combination of continuous rotary motion and atmospheric protection of the furnace tube enables the mixing and mixing of the materials in the tube to achieve uniform heating effect, which will bring you the ideal treatment result.

1200℃ low vacuum rotary CVD system applications:
The main application fields of the equipment are: powder metallurgy, ceramics, refractory materials, lithium battery anode and cathode materials, new energy and other industries particle powder firing, calcining, determination of materials.

1200℃ low vacuum rotary CVD system technical parameters:

Vacuum tube furnace	Max power	4.5kw
	Tube material	High purity quartz
	Tube diameter	60mm at both ends, 100mm in the middle
	Tube length	1400mm
	Furnace chamber length	600mm
	Heating zone length	200mm+200mm+200mm
	Operating temperature	0～1100℃
	Temperature control accuracy	±1℃
	Temperature control mode	30 or 50 segment program temperature control
	Display mode	Highlight digital display
	Sealing method	304 stainless steel vacuum flange
	Flange interface	1/4" ferrule connector, KF16/25/40 joint
	Vacuum	4.4E-3Pa
	Power supply	AC:220V 50/60Hz
	Inclination angle	0~15°
	Rotating speed	0~20 rpm
Gas supply system	Model	HS-3F
	Gas channel	3-channel
	Measuring unit	Gas float flowmeter
	Measuring range	A channel: 0～100ml H2 gas	Remarks: If you need other ranges or gas types, you need to specify when ordering. According to the customer's specific requirements, the flow meter of the corresponding gas type and range can be selected.
		B channel: 16～160ml N2 gas
		C channel: 25～250ml Ar gas
	measurement accuracy	±2.0%
	measurement accuracy	3MPa
	Working pressure difference	50～300KPa
	Connecting pipe	304 stainless steel
	Gas channel	304 stainless steel needle valve
	Interface specification	1/4" ferrule connector for gas inlet and outlet
Exhaust system	Mechanical pump	Rotary vane pump
	Pumping rate	1.1L/S
	Exhaust interface	KF16
	Vacuum measurement	Resistance gauge
	Ultimate vacuum	1.0E-1Pa
	Power supply	AC:220V 50/60Hz
	Pumping interface	KF16
