Item | Detail | |
Supply voltage | AC220V, 50Hz | |
Total power | 2.5KW | |
High voltage power supply | Input voltage | 0-30kV |
Max current | 0.5mA | |
Heating source | Heating method | Infrared heating tube |
Max temperature | Substrate temperatures up to 60℃ | |
Max heating power | 1000W | |
Syringe pump | Syringe capacity | 2.5ml~60ml |
Flow range | 2.779μl/min~72.24ml/min | |
Collector | Mandrel collector |
Six sets with various size: 200mm x φ100, 25, 12, 7, 6.0, 2.0mm; Actuator: brushless motor; mandrel shaft speed: 300-4000 rpm; used for electrospinning |
Plate collector | Dimensions: 320mm x 100mm x 2mm; Material: Stainless steel; for nanowire collection | |
Y-axis movable plate collector | Dimensions: 300mm x 200mm x 5mm; Material: Stainless steel; used to prepare film, computer program to control the way of moving |
